Key Specifications (Outrigger Equipped)
Specification
Value
Max Working Height
39 ft (11.9 m)
Max Platform Height
33 ft (9.96 m)
Platform Capacity
1,000 lbs (454 kg)
Machine Weight
8,560 lbs (3,882 kg)
Machine Length (with Outriggers)
12 ft 4 in (3.76 m)
Machine Width
5 ft 9 in (1.75 m)
Stowed Height
8 ft 6 in (2.59 m)
Gradeability (Stowed)
35%
